導體： GB/T 3956 第1種或第2種銅導體
絕緣： 無鹵低煙交聯聚烯烴
護套： PAO
| 型號Type | 名稱Designation | 額定電壓 Rating(V) |
芯數 Core N.0 |
標稱截面 Normal area of conductor(mm³) |
| WDZ-BYJ | 一般用途單芯硬導體無護套環保電纜 General-purpose single core hard conductor clean cable without sheath |
450/750V | 1 | 1~400 |
| WDZ-RYJ | 一般用途單芯軟導體無護套環保電纜 General-purpose single core soft conductor clean cable without sheath |
450/750V | 1 | 1.5~240 |
| WDZ-N-BYJ | 內部布線用導體溫度90℃的單芯實心導體無護套環保電纜 Inner wiring purpose,single core,solid conductor clean cable without sheath |
300/500V | 1 | 1 |
| WDZ-N-RYJ | 內部布線用導體溫度90℃的單芯軟導體無護套環保電纜 Inner wiring purpose,single core,soft conductor clean cable without sheath |
300/500V | 1 | 1 |
| WDZ-BYY | 輕型有護套環保電纜 Light type PO sheath clean cable |
300/500V | 1、2、3、4、5 | 1~35 |
| WDZ-BYJR | 銅芯環保軟電纜 Cu conductor PO insulation soft clean cable |
450/750V | 1 | 2.5~70 |
